Locking Trigger Latch-black finish Keyed CH501
Locking push button trigger black finish die cast zinc
Single point compression latch
Trigger latch has dust shutter on key cylinder to help reduce dirt from entering cylinder
Adjustable grip range is .013 inch minimum to a maximum of 2.43 inches

Locking trigger latch comes with:

• Single key
• Adjustable screw
• Mounting bracket
• Mounting screw
• Adjustment bolt both with hex heads for faster installation



Ideal for these locking trigger latch applications:

• Compartment door latches
• Cabinet door latches
• Marine latches / Boat compartment latches
• Work truck compartment door latches
• Bus baggage compartment latches

Locking Trigger Latch Specifications
Keyed 501
Material: Zinc die cast
Finish:  Black
Overall length: 4.11 in.
Width: 1.0 in.
Grip Range: 0.13 in. to 2.43 in
