TriMark Rotary Latch-Two Rotor Latch
with Release Linkage
Medium to Heavy Duty Rotary Latch
Features an integrated linkage -allows for direct
L handle actuation and provides for ease of mounting and applications
FMVSS 206 compliant
Two-Rotor Latch & Release Linkage complies with FMVSS 206 -ONLY when tested with approved
TriMark FMVSS 206 Striker Bolts in accordance with SAE J839
Product does not meet the locking requirements for FMVSS 206
Rotary Latch Options
Left or Right Hand
Push Release Lever
Remote Release Lever
Rotary Latch Material
Internal latch components: heat treated, smooth edge stamped steel
Case halves: high strength steel
Springs: non-corrosive stainless steel
Rotary Latch Finish
Zinc plated, yellow chromate steel components
Rotary Latch Installation
- Four 1/4-20 UNC grade 5 mounting fasteners (not included)
- Tighten to the fastener manufacturer's recommended torque value; do not exceed 120 in-lbs.
- Maximum 0.312 in. diameter mounting holes
See Data Sheet for Additional Detailed Latch & Striker Installation
Dual Stage Rotary Latch is Ideal for:
- Medium to heavy-duty applications for on-highway
or off-highway entrance doors
- Compartment and access panesl with:
- Door thicknesses of 1-7/8 in. or greater
- Door weights of 50-200 lbs.
- Door seal pressures of 50-150 lbs.
(suggested for best results)
- TriMark 070-0200 Striker Bolt
