Accuride 3832 Industrial Drawer Slide
Accuride 10 inch drawer slides are medium duty, precision ball bearing industrial drawer slides for medium loads up to 100 lb. capacity.
Use Accuride 3832 full extension drawer slides whenever a medium duty positive stop, non-disconnect over travel industrial drawer slide is required.
For use in medium-duty industrial drawers, trays, pull-out shelves or electronic enclosure applications including:
- EIA rack-mount chassis drawer slides
- Power Supply drawer slides
- Disc/Tape drive drawer slides
- Industrial work station drawer slides
- Dispensing equipment drawer slides
PRICE IS PER PAIR
Requires #8 pan head screws (not included)
Optional bracket kit available for electronic enclosure mounting
RoHS Compliant
BHMA/AWI Certified
Accuride 3832 10 Inch Drawer Slide Specifications
- 10 Inch Drawer Slide
- Up to 100 LBS load capacity
- Height 1.8 in.
- 1 inch over travel
- 0.50 inch side space
- Tested drawer width 10 in.
- Front disconnect latch
- Full extension
- Clear zinc electroplate finish
- Front face frame hole
Special Features
- Drawer member vertical adjustment cam
- Hold-in detent prevemts drawer roll-out and bounce back
- Silcenced open and closed
