30 INCH LH HEAVY DUTY LOCKING DRAWER SLIDE-ACCURIDE 9308E

  • SKU: ARC9308-30LH
  • Category: Locking Drawer Slides
  • Brand: Accuride
    130.76
  • $130.76
Out of Stock

Accuride 9308E 30 Inch Left Hand Heavy Duty Industrial Drawer Slide
Accuride 30 inch left hand drawer slides are precision ball bearing, full extension, locking industrial drawer slides for extra heavy loads up to 500 lb. capacity.

The Accuride 30 inch left hand  heavy duty locking drawer slide is designed for heavy duty, lock-in and lock-out drawer slide applications up to 500 lbs. including:

  • RV storage drawer slides
  • Electronic instrumentation chassis drawer slides
  • Heavy duty storage drawer slides
  • Vehicle battery tray drawer slides
  • Toolbox drawer slides
  • Service truck tool drawer slides

PRICE IS PER EACH (HAND)
Screws not included
Side Mount
RoHS Compliant






Accuride 9308E 30 Inch Left Hand Full Extension Lock-In and Lock-Out Heavy Duty Drawer Slide Specifications

  • 30 Inch Left Hand Heavy Duty Locking Drawer Slide
  • Up to 500 LBS capacity
  • Height 3 in.
  • Full Extension
  • Side Mount
  • 0.75 inch side space
  • Non-disconnect
  • Tested drawer width 30 in.
  • Even lengths 30 in.
  • Clear zinc electroplate finish



  Load Ratings

  • Mobile applications: 360 lbs., drawer widths up to 32 in.
  • Frequent usage: 480 lbs., drawer widths up to 42 in.
  • Moderate usage: 600 lbs., drawer widths up to 24 in.

For additional load ratings,please consult the technical data sheet.

Special Features

  • Enhanced Lock-In/Lock-Out Spring and Lever make slides more reliable
  • Bridged ball spacers minimize side-to-side movement, help increase the load rating up to 20%, improve full-extension and over-travel reliability, produce smoother and more consistent movement
  • Added shock absorbing ball spacer bumpers help reduce the end stop and lower the impact noise
  • 13% increase in inner and outer member thickness contributes to 20% increased payload
  • Optional platform bracket kit allows for additional bottom and side mount applications
  • Model 9308E may be installed as a companion slide with Model 9301E (non-locking)
