Eberhard Eclipse Non-Locking Latch-230 Series
Eberhard 230 Series Eclipse latch
Squeeze latch features a pinch method of activation for specialized use
Non-Locking compression latch

230 Series Latch Materials
Squeeze Latch and housing are manufactured from high strength, UV stabilized thermoplastic
Metal stampings are 300 Series Stainless Steel

Easy Installation

• Installation is fast with the use of the mounting bracket and (2) screws, which are provided.
• An oil-resistant flange gasket is also provided.
• Torque mounting bracket screws to 14 ± 3 in./lbs.
• No external fasteners needed.
• No weld marks to mar finish.
• Eclipse latches can be assembled on finished panels.

Eclipse 230 Series Non-Locking Latch is ideal for:
Electronic enclosure latch
Food service latch
Medical enclosure latch

Latch Features:
Rubber grommet which swells into a doughnut shape when the handle is folded into the recessed housing.
In the compressed state, the grommet is larger than the hole in the strike effectively “locking” the panel.
When the handle is lifted the grommet relaxes, allowing it to pass through the strike hole.
